McMenon supplied a range of precision differential pressure flow measurement assemblies for a chemical process plant upgrade in Paraguay. The project required reliable flow measurement across multiple process services, supporting the efficient operation of critical plant systems.
To meet the project's requirements, McMenon supplied two FPD175 Compact Orifice Carrier Assemblies and two FPD160 Orifice Flange Assemblies, in sizes ranging from 1" to 4".
Product family
Orifice Plates
01 / The challenge
The Challenge
The upgraded process plant required accurate and dependable flow measurement across a variety of applications, including gas and liquid services. Each measurement point had different operating conditions, requiring engineered solutions capable of delivering consistent performance while meeting international pressure and piping standards.
02 / McMenon's solution
McMenon's Solution
McMenon's engineered differential pressure flow measurement assemblies were supplied for the measurement of:
- Nitrogen
- Combustion air
- Cooling water
- Absorbing water
The supplied assemblies incorporated precision-machined concentric square-edged orifice plates manufactured from 316/316L stainless steel, installed within carbon steel flange assemblies designed to meet the project's pressure and installation requirements.
For gas service applications, McMenon's FPD175 Compact Orifice Carrier Assembly was selected, providing a compact solution complete with an integral three-valve manifold for simplified installation and maintenance.
For liquid service applications, FPD160 Orifice Flange Assemblies were supplied, engineered to deliver accurate, repeatable flow measurement while ensuring reliable long-term performance.
Project highlights
At a glance
- 4 differential pressure flow measurement assemblies supplied
- FPD175 Compact Orifice Carrier Assemblies
- FPD160 Orifice Flange Assemblies
- Sizes ranging from 1" to 4"
- Designed for gas and liquid flow measurement
- 316/316L stainless steel orifice plates
- Integral three-valve manifolds for simplified installation
- Suitable for horizontal pipeline installation
03 / Project result
Delivering Reliable Process Measurement
By supplying application-specific flow measurement solutions for multiple process services, McMenon helped support the successful upgrade of a critical chemical processing facility. The project demonstrates McMenon's ability to engineer reliable differential pressure flow measurement systems that deliver accurate performance across a wide range of industrial applications, while meeting demanding project specifications and international standards.
